Focus Areas of Research

Research on Power Supply on Cchip (Power SoC), aimed at realizing ultimate miniaturization of power sources.


Concept of PowerSoC(a) and next generation 3D-PowerSoC(b).

Quality assessment techniques for next-generation power semiconductor wafers.


Wafer quality measurement setup and the principle of the detection.

Development of ultra-compact current sensor array inspection equipment for power module screening.


Power module screening equipment prototype with current sensor array.

Research and development of next-generation electrical network systems, led by ultra-compact power sources.


Next generation high power density (12W/cc) DC-DC converter.

Research on wireless electricity transmission technologies

Research on wireless electricity transmission technologies
Demonstration of the wireless power transmission through thick insulation material

Research on high-performance silicon power devices to reduce the per unit negawatt cost.


  Concept of next generation IGBT and high speed diode.

Real-time monitoring technology improve the reliability of power semiconductor devices.


SAT based real-time monitoring of IGBT module package under power stress test.


Temperature distribution imaging by real-time simulation.

Evaluation Circuit with Small Inverter for Capacitors

実リブル電流での評価を電力価格1/10のインバータで実現
Evaluation by Actual Ripple Current Waveform with 1/10-Power- Rating Small Inverter

実リブル電流での評価を電力価格1/10のインバータで実現

Development of a full-scale power test bed.


Concept of researches with full scale power test bed.


  Full scale power test bed (5kV 100A).

Patent

公開番号公開日発明の名称
特開2012-243918平成24年12月10日半導体装置及びその駆動方法
【国際公開番号】WO 2012/157608 A1 2012年11月22日
【台湾公開番号】201312761 2013年3月16日
特許第5721137号平成27年4月3日半導体装置の短絡保護装置
特開2013-76569平成25年4月25日半導体回路の電流測定装置
特開2013-251338平成25年12月12日高電圧電力用半導体装置
PCT/JP 2013/0649432013年5月29日高電圧絶縁ゲート型電力用半導体装置およびその製造方法
【国際公開番号】WO 2013/180186 A12013年12月5日
